Brand ERYCO
Product origin CHINA
Characteristics
Rated Current: 0.05~10A, 12A Max
Turns Ratio: 1:1500
Load Resistance: 75Ωmax
Operation Frequency: 50Hz~10kHz
Dielectric Strength between primary and secondary >4kV/1min.
Accuracy: 0.5Class
Phase displacement <90′, AC current error < ±1.5%.
Ambient Temperature: -40℃~+80℃
Relative Humidity:≤95% (25℃) Altitude: ≤10000m.
Features CT010P-C2 without DC Immunity For kWh meter , Class 1.0, Class 2.0. Very reliable and stable performance at different temperature conditions. Good linearity, it support automatically software calibration. Different type for different fixing and assembly easily. Quick connection to PCB available on request. RoHS Compliance is available on request.
