Product parameter:
Material:
Housing: PA6T
UL94V-0
Contacts: Brass
Plating: Gold
plated: 0.8u" over 50u" nickel
Electrical
Characteristics:
Current Rating:
1.0 AMP
Insulator
Resistance: 1000M Ohm min.
Contact
Resistance: 20m Ohm max.
Withstanding
Voltage:AC 500V/Minute
Operating
Temperature: -45ºC~+105ºC
Applications
1. Test and
Measurement Instruments
2. LED Lighting
Systems
3. Security
Systems
4. Audio-Visual Equipment
Features
-Mounting
Type:Designed for surface-mounting on PCBs using reflow soldering processes.
SMD pin headers feature solder tails or pads that adhere to the PCB surface,
ensuring secure attachment and electrical connectivity.
-Current Rating:Rated
for a range of current levels depending on the pin size, material, and
configuration. SMD pin headers are suitable for low to moderate current
applications typical in consumer electronics and industrial devices.
-Operating
Temperature Range:Designed to operate within a specified temperature range,
often from -40°C to +105°C or higher, ensuring suitability for various
environmental conditions and applications.
-Customization:Can
be customized in terms of pin length, plating thickness, insulator color, and
other specifications to meet specific design requirements and application
needs.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
