Product parameter:
Material:
Housing:
PBT/PA46/PA9T UL94V-0
Contacts: Phosphor
bronze
Plating:Sn over
50u" nickel
Electrical
Characteristics:
Current Rating:
1.0 AMP
Voltage Rating:
230V AC/DC
Withstand
voltage:500V AC/Minute
Contact
Resistance: 20m Ohm max.
Insulator
Resistance: 1000M Ohm min.
Operating
Temperature: -40ºC~+105ºC
Applications
1.Industrial
Automation and Control Systems
2.Medical and
Laboratory Equipment
3.Automotive
Electronics
4.Aviation and
Aerospace Applications
Features
-Pin
Configuration: Usually available with various pin counts, typically ranging
from 10 to 24 pins, arranged in a single row.
-Mounting:
Designed for through-hole mounting on PCBs, providing a secure and reliable
connection.
-Durability:
Constructed from durable materials to withstand mechanical stress and ensure
long-term reliability in electrical connections.
-Electrical
Performance: Provides low contact resistance and reliable signal transmission, suitable
for digital and low-frequency analog signals.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
