Product parameter:
Material:
◆Material: Nylon UL 94V0 (Lead Free)
◆Contact : Phosphor Bronze
◆Finish : Plated Tin or Gold Flash Lead over Nickel
◆Current rating:2A AC,DC
◆Voltage rating:125V AC,DC
◆Temperature range:-35℃~+85℃
◆Insulationresistance:1000MΩ/Min.
◆Withstanding voltage:800V AC/minute
◆Contact resistance:20mΩ/Max.
Applications
1.Telecommunication
Equipment:
2.Medical Devices:
3.IoT (Internet of
Things) Devices:
4.LED Lighting
Systems:
Features
-Operating
Conditions: Designed to operate within a wide range of temperatures, typically
between -25°C to +85°C or higher, ensuring reliable performance in various
environmental conditions.
-Termination
Options: Supports various wire termination methods including crimping and
soldering. Some models may also support IDC (Insulation Displacement Contact)
termination, offering flexibility in assembly processes.
-Certification:
Complies with industry standards and certifications such as UL, RoHS, and
REACH, ensuring reliability, safety, and environmental compatibility.
-Design: Compact
and space-saving design suitable for applications where board space is limited
but reliable connectivity is crucial.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
