Product parameter:
Material:
Material: PA66/LCP
UL 94V-0
Contact : Brass
Finish : Plated
Tin over Nickel
Current
rating:3.0A AC,DC
Voltage
rating:250V AC,DC
Temperature
range:-45℃~+105℃
Insulationresistance:1000MΩ
Min.
Withstanding
voltage:1000V AC minute
Contact
resistance:30mΩ Max.
Wire range : AWG#24~#30
Applications
1.Telecommunications
Equipment
2.Industrial
Equipment
3.Automotive
Electronics
4.Medical Devices
Features
-Electrical
Performance: Capable of handling moderate currents, depending on the specific
model and configuration, ensuring safe operation under typical electronic
loads.
-Materials:
Contacts are typically made from phosphor bronze with tin or gold plating. This
choice of materials provides good conductivity, durability, and resistance to
corrosion, ensuring long-term reliability.
-Keying: Designed
with polarization features such as keying slots or tabs to prevent incorrect
insertion and ensure proper orientation of the connector. This feature helps in
avoiding damage to the connector and the circuit.
-Operating
Conditions: Designed to operate within a wide range of temperatures, typically
between -25°C to +85°C or higher, ensuring reliable performance in various
environmental conditions.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
