Brand ERYCO
Product origin CHINA
Rated Voltage: 250V AC.DC
Rated Current: 7A
Contact Resistance: 0.02 Ohm max
Insulation Resistance: 1000M Ohm min
Withstand voltage: 1500V AC/MIN
Temperature range for usage : -25ºC~+85ºC
P.C board thickness : 1.6mm
Product parameter:
Material:
Housing: PA66 (PA66) UL94V-2
Contacts: Brass or Phosphor Bronze
Plating: Tin 50u" over 100u" nickel
Wire range : AWG#24#18
Applications
1.Industrial Equipment
2.Telecommunications
3.Medical Devices
4.LED Lighting Systems
Features
-Housing Material: Typically made of durable thermoplastic materials such as nylon or polyester. The housing provides mechanical strength, insulation, and protection against environmental factors.
-Contact Material: Contacts are usually made from phosphor bronze with tin or gold plating. Gold plating enhances conductivity and provides resistance to corrosion.
-Polarization: Designed with polarization features to prevent incorrect insertion and ensure proper alignment between the connector and PCB.
-Locking Mechanism: Some models feature locking mechanisms or friction locks to secure the connector to the PCB, preventing accidental disconnection due to vibrations or pulling.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
