Brand ERYCO
Product origin CHINA
Electrical Specification:
Rated Voltage: 300V AC.DC
Rated Current: 9A
Contact Resistance: 0.015Ω max
Insulation Resistance: 1000MΩ min
Withstand voltage: 1500V AC/MIN
Temperature range for usage : -40ºC~+105ºC
Product parameter:
Material:
Housing: PA66 (PA66) UL94V-2
Contacts: Phosphor Bronze or Brass
Plating: Tin 50u" over 100u" nickel
Wire range : AWG#30~#22
Applications
1.Power Supply and Distribution
2.Industrial Equipment and Machinery
3.Automotive Electronics
4.Telecommunications and Networking
Features
-Polarization: Designed with polarization features to prevent incorrect insertion and ensure proper alignment between the connector and PCB. This helps avoid damage and ensures reliable connections.
-Locking Mechanism: Many models include a locking mechanism (such as a latch or friction lock) to secure the connector to the PCB, preventing accidental disconnection due to vibrations or pulling.
-Voltage Rating: Supports a specific voltage range suitable for the intended application, ensuring safe and reliable operation.
-Current Capacity: Designed to handle a specific current capacity, ranging from moderate to high current levels depending on the series (5557 or 5559).
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
