Product parameter:
Material:
Housing: PBT+30%
Glass filled ,UL94V-0
Contacts: Brass ,
Gold Plating on Contact Arer, Tin on
Solder Tail.
Shell: Steel,
Front Shell Nickel Plating, Back Shell
Tin Plating
Electrical
Characteristics:
Current Rating: 5
AMP
Insulator
Resistance: 1000MΩ Min. at DC 500V
Withstanding
Voltage: 500V AC (rms) for 1 minute
Contact
Resistance: 20mΩ Max. Initial
Operating
Temperature: -55°C~+105°C
Applications
1.Medical Devices
2.Test and
Measurement Instruments
3.Military and
Aerospace Applications
4.Automotive
Electronics
Features
-Number of Pins:
Available configurations include 15P, 26P, 44P, and 62P (refers to the number
of signal pins)
-Termination Type:
Simple Solder Type, designed for soldering directly to PCB pads for a secure
and reliable connection.
-Material: Often
constructed from metal (e.g., steel, brass) for durability and good electrical
conductivity.
-Shielding: Provides
electromagnetic interference (EMI) shielding, crucial for applications
requiring noise reduction and signal integrity.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
