Product parameter:
Material:
Housing: PBT+30%
Glass filled ,UL94V-0
Contacts: Brass
,Gold Plating
Electrical
Characteristics:
Current Rating: 5
AMP
Insulator
Resistance: 1000MΩ Min. at DC 500V
Withstanding
Voltage: 500V AC (rms) for 1 minute
Contact
Resistance: 20mΩ Max. Initial
Operating
Temperature: -55°C~+105°C
Applications
1.Printed Circuit
Board (PCB) Interconnections
2. Industrial
Applications
3. Consumer Electronics
4.Telecommunications
Features
-Pitch: The pitch
refers to the distance between adjacent pins or contacts. In this case, it is
2.0mm, which is the standard spacing for this type of connector.
-Number of
Contacts: Female header connectors come in various configurations with
different numbers of contacts (pins). These can range from single-row
configurations with a few pins to dual-row configurations with many pins,
depending on the specific application requirements.
-Height: The
height of 4.3mm specifies how much vertical space the connector occupies on a
PCB when soldered or mounted. This height provides adequate clearance and
mechanical stability for applications where slightly taller connectors are
needed.
-Connector Type:
It is a female header connector, meaning it has receptacles or sockets that
accept male pins or headers. This configuration allows for easy mating and
unmating of connections, making it suitable for board-to-board or board-to-wire
applications.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
