Product parameter:
Material:
Housing: 30% Glass
filled PBT UL94V-0
Contacts: Brass or
Phosphor Bronze
Shell: Steel,
100u" Tin Over 50u" min Nickel
Clinch Nut: Brass,
100u" min Nickel Plated
Screwlock: Brass,
100u" min Nickel Plated
Electrical
Characteristics:
Current Rating:
2AMP
Insulator Resistance:
5000M ohms min. at DC 500V
Contact Resistance:
20m ohms max. at DC 100mA
Operating
Temperature: -55ºC~+105ºC
Applications
1.Telecommunications
2.Test and
Measurement Instruments
3.Aerospace and
Defense
4.Medical Devices
Features
-High Pin Density:
Provides a high pin density in a compact space, allowing for multiple signal
lines to be transmitted through a single connector.
-Standard Size:
Follows industry-standard sizes for D-Sub connectors, ensuring compatibility
with existing equipment and systems.
-Metal Shell:
Typically made from steel or other durable metals, providing mechanical
strength and EMI shielding properties. Plastic shells are also used in some
applications for lighter weight and cost efficiency.
-Contacts: Made
from materials such as phosphor bronze or brass, offering good electrical
conductivity and resistance to corrosion. Gold plating on contacts enhances
conductivity and prevents oxidation, ensuring reliable signal transmission.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
