Product parameter:
Material:
Contact current
rating:0.5A Max.
Contact
resistance:100mΩ Max.
Insulation
Resistance:250V DC or 300V AC for no less than 1 minute
Mating durability:10000
Cycles Min.
Insertion
force:2.0kgf max.
Extraction
force:0.5kgf min.
Operating
Temperature: -25ºC~+85ºC
Applications
1.Termination
Style
2.Current Rating
and Voltage
3.Keying and
Polarization
4.Environmental
Considerations
Features
-Height: Specifically
designed with a height of 1.85mm, making it suitable for various electronic
devices where space is limited but not as compact as lower-profile variants.
-"Normally
Open" Configuration: This term typically refers to the switch inside the
SD card slot. A "Normally Open" switch means that when the SD card is
inserted, it closes a circuit to signal its presence or readiness. This
configuration is important for devices that need to detect when an SD card is
inserted or removed automatically.
-Durability:
Constructed from durable materials to withstand repeated insertion and removal
cycles, ensuring longevity and reliability.
-Electrical
Performance: Provides secure electrical contacts with low contact resistance,
ensuring reliable data transfer between the Micro SD card and the device.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
