Brand ERYCO
Product origin CHINA
Housing:Hing Temperature Thermoplastic,UL94V-0 PBT/LCP,Black/White.
Contact:Copper Alloy C2680.
Shell:Copper Alloy C2680/SPCC.
Finish:
Contact:Plated Gold In Mating Area;Tin On Solder Tails.
Shell:Nickel Plating.
Product parameter:
Material:
Current Rating:1.5A/Contact Terminal.
Voltage Rating:30V DC
Contact Resistance:30mΩ Max.
Dielectric Withstanding Voltage:500 V AC AT Sea Level.
Insulation Resistance:1000MΩ Min.
Connector Mate and Unmated Force
Mate Force:3.75kgf Max.
Unmated Force:1.02kgf Min.
Terminal Retenion:1
Applications
1.Motherboards and Expansion Cards
2.Embedded Systems
3.Consumer Electronics
4.Industrial Equipment
Features
-USB Standard Compatibility: Supports various USB standards such as USB 2.0 or USB 3.0, depending on the specific model. USB 3.0 connectors offer higher data transfer rates compared to USB 2.0.
-Orientation: The 180-degree orientation indicates that the connector is designed to be mounted horizontally on the PCB (Printed Circuit Board), with the pins extending out from both sides of the connector body.
-Number of Pins: Typically, USB connectors have four pins: VCC (Power), Data+, Data-, and Ground (GND). These pins facilitate power delivery and data transfer between devices.
-Mechanical Durability: Designed to withstand multiple insertion and removal cycles, ensuring reliable performance over the connector's lifespan.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
