Brand ERYCO
Product origin CHINA
Material
Housing: Thermoplastic
Contacts: copper
Pin Plated: Gold 3u" over 50u" nickel
Shell: Spcc,Nickel plated
Product parameter:
Material:
Contact Current Rating:1.5 A
Withstanding Voltage:500VAC(Rms)
Contact Resistance: 30mΩ Max
Insulation Resistance:1000MΩ Min
Mechanical
Operating Temperature:-30°C TO +80°C.
Applications
1.External Displays and Monitors
2.Networking Devices
3.Gaming Devices
4.Industrial Automation
Features
-USB 3.0 Standard:Compliant with USB 3.0 specifications, offering enhanced data transfer rates (up to 5 Gbps) compared to USB 2.0, making it suitable for high-speed data applications.
-Connector Type:A Male Connector: Typically used for connecting to downstream devices such as computers, laptops, hubs, and other peripherals.
-SMT (Surface-Mount Technology):Designed for direct soldering onto the surface of a printed circuit board (PCB), allowing for automated assembly processes and reducing production time.
-Number of Pins:The connector includes the standard 9 pins required for USB 3.0 connectivity: 4 for data transfer (Tx and Rx pairs), 1 for ground, and 4 for power and other signals.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
