Brand ERYCO
Product origin CHINA
Voltage Current Rating:2AMP,30V AC
Insulator Resistance: 100MΩ Min
Contact Resistance: 50mΩ Max
Withstanding Voltage: 300V AC
Product parameter:
Material:
Operating Temperature:-55°C TO +85°C.
Mating Force: 35N MAX
Unmating Force: 10N MIN.
Applications
1.External Hard Drives and SSDs
2.Printers and Scanners
3.Audio Interfaces and Recording Equipment
4.Video Cameras and Camcorders
Features
-Compatibility: Compliant with USB 3.0 specifications, ensuring compatibility with devices requiring high-speed data transfer rates and backward compatibility with USB 2.0 devices.
-Design: Engineered for durability and reliability, featuring a sturdy housing and contacts that withstand frequent insertion and removal cycles.
-Speed: Supports SuperSpeed USB 3.0 data transfer rates up to 5 Gbps, enabling rapid data transfer for large files, multimedia content, and high-definition video.
-Power Delivery: Capable of enhanced power delivery compared to USB 2.0 connectors, supporting higher power output for charging and powering devices.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
