Product parameter:
Material:
Current
Rating:1.5A/Contact Terminal.
Voltage Rating:30V
DC
Contact
Resistance:30mΩ Max.
Dielectric
Withstanding Voltage:500 V AC AT Sea Level.
Insulation Resistance:1000MΩ
Min.
Connector Mate and
Unmated Force
Mate Force:3.75kgf
Max.
Unmated
Force:1.02kgf Min.
Terminal
Retenion:1.2kgf Min.
Applications
1.Laptops and
Desktop Computers
2.Tablets and
Smartphones
3.Consumer
Electronics
4.Gaming Consoles
Features
-3.4mm Height:
Indicates the profile or height of the connector above the PCB surface once
mounted. This measurement is crucial for determining the space requirements and
clearance in the device design.
-Compact Size: The
3.4mm height suggests a compact design suitable for applications where space is
limited or where a low-profile connector is preferred.
-Robust Design:
USB connectors are designed to withstand repeated insertions and removals,
ensuring durability and reliability in various operating conditions.
-Versatile
Application: Used in a wide range of electronic devices where USB connectivity
is required, including computers, laptops, tablets, smartphones, gaming
consoles, peripherals (such as keyboards, mice, printers), and consumer electronics.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
