Product parameter:
Material:
Insulator:Hi-Temperature
plastic,UL94V-0,Black
Terminal:Copper
Alloy,Gold Flash Plating On All Terminal, And 50u" min nickel underplated
on allover.
Shell:Stainless
Steel,50u" Nickel underplated on allover,gold flash on solder pad.
Applications
1.Mobile Phones
2.Tablets and
Laptops
3.Internet of
Things (IoT) Devices
4.Embedded Systems
5.Portable Routers
and Modems
Features
-6P+1P or 8P+1P
Pin Configuration: Available in two configurations—6 pins plus 1 ground pin
(6P+1P) or 8 pins plus 1 ground pin (8P+1P)—for versatile applications
depending on the device's requirements for data and power connections.
-Secure SIM Card Insertion
and Removal: The push-push mechanism ensures the SIM card stays securely in
place during use, and its design minimizes the risk of accidental ejection or
disconnection.
-Pitch (H1.50mm):
This indicates the spacing between the pins or contacts, often referred to as
the pitch. H1.50mm specifically means a pitch of 1.50mm between adjacent pins.
-Push-Push
Mechanism: This refers to the type of connector where you push the SIM card
into the slot until it clicks into place, and then push again to eject it. It's
a convenient mechanism for easy insertion and removal of the SIM card.
-Efficient Space
Utilization: The compact size of the connector helps optimize space on the
circuit board, making it an excellent choice for devices with constrained
internal space.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
