Brand ERYCO
Product origin CHINA
Current Rating: 3.0A Max
Voltage: 100 VAC
Contact Resistance: 40mΩ Max
Insulation Resistance: 100MΩ Min.
Product parameter:
Material:
Operating Temperature:-30°C TO +85°C.
Insertion Force : 5N~20N
Unmating Force: 8N~20N
Durability:10000 Cycles
Applications
1.Industrial and Embedded Systems
2.Medical Devices
3.Telecommunications
4.Audio/Video Equipment
Features
-DIP (Dual In-line Package) and SMD (Surface Mount Device): Combines through-hole and surface mount technologies. The through-hole pins provide mechanical stability, while the surface mount pads allow for automated assembly processes.
-10.0mm Length: Provides a larger footprint and more stable connection on the PCB, suitable for applications where durability and reliability are critical.
-Housing Material: Made from high-temperature thermoplastics, ensuring durability and insulation during soldering.
-Metal Shielding: Often includes metal shielding to reduce electromagnetic interference (EMI) and ensure signal integrity.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
