Product parameter:
Material:
Insulator:High Temperature
Thermoplastic,UL94V-0.
Contact:C5210.Plated
50u" Ni Overall,Contact All Au 1u.
Shell:SUS,Plated
50u" Ni Overall,PAD Au 1u.
Electrical:
Current
Rating:0.5A AC/DC max.
Voltage
Rating:125V AC/DC
Contact
Resistance:100mΩ Max.
Insulation
Resistance:1000MΩ Min.500V DC
Operating
Temperature: -45ºC~+85ºC
Applications
1.Smartphones
2.Tablets
3.Wearable Devices
4.Laptops and
Notebooks
Features
-Compact
Size:Designed for nano SIM cards, which are the smallest standard SIM cards,
reducing the overall footprint in electronic devices.
-Secure SIM Card
Retention: The PUSH-PULL mechanism ensures that the SIM card is securely
retained during device operation, preventing accidental ejection or poor
contact.
-Pin
Configuration:Typically includes 6 pins to ensure full functionality and
compatibility with standard nano SIM cards, supporting all necessary electrical
connections.
-Low Profile:With
a height of 1.35mm, it is suitable for ultra-slim devices, helping to maintain
a sleek and compact design.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
