Brand ERYCO
Product origin CHINA
Electrical
Rated voltage: 300V
Rated current: 8A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Product parameter:
Material:
Contact: Brass,Sn Plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
Torque: 0.5Nm (3lb.in)
Strip length: 7-8mm
Applications
1.Printed Circuit Board (PCB) Assemblies
2.Industrial Control Systems
3.Telecommunications Equipment
4.Consumer Electronics
Features
-Voltage Rating: Indicates the maximum voltage (in volts) that the terminal block can withstand, ensuring safe operation within specified electrical parameters.
-Wire Size Compatibility: Supports a range of wire sizes, accommodating various conductor diameters commonly used in electronics and electrical applications.
-Material: Made from materials such as brass, copper, or tin-plated copper for good electrical conductivity, corrosion resistance, and mechanical strength. The housing material is typically a robust thermoplastic that provides insulation and mechanical support.
-Current Rating: Specifies the maximum current carrying capacity (in amps) that the terminal block can safely handle, ensuring safe operation under specified electrical conditions.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
