Brand ERYCO
Product origin CHINA
Electrical
Rated voltage: 300V
Rated current: 8A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Product parameter:
Material:
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Applications
1.Automotive Electronics
2.LED Lighting Systems
3.Medical Devices
4.Power Supplies and Battery Management
Features
-able terminals facilitate quick assembly and maintenance.
-Mounting Options: Designed for PCB (Printed Circuit Board) mounting using through-hole or surface mount techn
-ology (SMT), depending on the specific design. This allows for flexible installation options on PCBs.
-Orientation: Available in vertical and horizontalPitch Size: Refers to the center-to-center spacing between adjacent terminals. The 3.81mm pitch accommodates various wire sizes and is standard in electronic PCB designs.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
