Product origin CHINA
Electrical
Rated voltage: 300V
Rated current: 8A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Wire range: 24-16AWG 1.5mm²
Product parameter:
Material:
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
Strip length:9-10mm
Applications
1.Printed Circuit Board (PCB) Assemblies
2.Industrial Control Systems
3.Telecommunications Equipment
4.Consumer Electronics
Features
-Pitch Size: Refers to the center-to-center spacing between adjacent pins or terminals. The 3.50mm pitch allows compatibility with various electronic components and PCB designs.
-Connector Type: Designed with male pins or headers that plug into corresponding female sockets or receptacles on the opposite terminal block. This facilitates easy and secure connections and disconnections of wires or components.
-Terminal Type: Utilizes screw terminals, spring terminals, or other types of connectors for wire termination. This ensures a secure and reliable electrical contact.
-Material: Made from materials such as brass, copper, or tin-plated copper for good electrical conductivity, corrosion resistance, and mechanical strength. The housing material is typically a robust thermoplastic that provides insulation and mechanical support.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
