Product parameter:
Material:
Base & Cover:
PPS (UL94V-0)
Actuator: PA46
(UL94V-0).
Contacts: Brass,
Gold /Tin Plate
Terminals: Brass,
Gold /Tin Plate
100 mA at 50VDC(steady state)
Life: 1,000 cycles
Contact Resistance: 100mΩ Max.
Insulation Resistance: 100MΩ at 100VDC Min
Dielectric Strength: 300VAC Min
Storage Tempeeature: -40°C ~ 85°C
Operating Tempeeature: -25°C ~ 70°C.
Operation Force: 9.8N Max.
Applications
1.Embedded Systems
& Microcontrollers
2.Industrial
Automation & Control Systems
3.Networking &
Communication Devices
4.Consumer
Electronics
Features
-Voltage Rating:
Typically 12V to 24V DC (varies by model).
-Current Rating:
Usually 25mA to 100mA.
-Dielectric
Strength: Withstands high voltage without breakdown.
-Housing Material:
High-temperature plastic (PBT, PA6T) for heat resistance.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
