Tactile Switch:ERYGYS6601

Tactile Switch:ERYGYS6601

Brand ERYCO

Product origin CHINA

Tactile Switch

ELECTRICAL

1.Rating: 50mA 12VDC

2.Contact Resistance : 50mΩ max(initial)

3.Insulation Resistance: 100MΩ(minDC 250V)

4.Dielectric Strength : AC250V(50/60Hz for 1minute)

5.Electrically Life: 100000cycles

6.Environment temperature:-20ºC~+70ºC

7.Operating Force: 180/250(±30gf)

8.Seal temperature:260ºC~ 280ºC

9.Operating temperature:-40ºC~+85ºC

2D(PDF)Drawing

Product parameter:

Applications

1. Home Appliances

2. Automotive Applications

3. Industrial and Manufacturing Equipment

4. Security Systems

Features

-Enhanced User Experience: The tactile response ensures that users know the switch has been pressed, making it useful for applications like keyboards, game controllers, and consumer electronics.

-Space-Efficient Design: Tactile switches come in small sizes, typically ranging from 2x2mm to 12x12mm, making them ideal for use in space-constrained applications.

-Energy Efficient: Tactile switches use very little power, making them suitable for battery-operated devices like remote controls, wearable devices, and IoT products.

-Minimal Current Draw: They have low contact resistance, which ensures they don't drain much power and help extend battery life.ns.

Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
