Product parameter:
Material:
Frequency
tolerance (at +25°C)：±10x10-6
Equivalent series
resistance：Please Refer to
the Following ESR Table
Load capacitance：Series, 10pF, 12pF, 16pF
Shunt capacitance：5pF max.
Level of drive：10μ W （100μ .W max）
Applications
1.Microcontroller
Clock Sources
2.Wireless
Communication Modules
3.Wearable and
Portable Devices
4.Smartphones and
Tablets
Features
-Ideal for
space-constrained designs such as smartphones, wearables, and compact embedded
systems.
-Precise frequency
control for clock generation in microcontrollers, RF modules, and timing
circuits.
-Low ESR
(typically 50–100 Ω), suitable for high-frequency and low-power oscillator
circuits.
-Temperature
Stability: Often includes temperature-compensated cuts or materials to minimize
frequency variations across temperature ranges, ensuring reliable operation in
various environmental conditions.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
