Product parameter:
Material:
1.Voltage
ratign:125V AC.
2.Insulation resistance:
500 megohms MIN @500VDC.
3.Contact
resistance: 50 milliohms Max.
4.T/R: TX=1CT:1CT(?2%)
& RX=1CT:1CT(?2%).
5.OCL:350uH Min.at
100KHz 100mV 8mA DC.
6.Insertion Loss:-1.0
dB Max 1MHz to 100MHz.
7.Return loss:-16dB
Min From 1MHz to 30MHz;
-14dB Min From
30MHz to 60MHz.
-10dB Min From
60MHz to 80MHz.
8.Cross talk:
-40dB Min From 1MHz-30MHz;
-35dB Min From
30MHz-60MHz;
-30dB Min From
60MHz-100MHz;
9.CMR: -35dB Min
From 1MHz-100MHz;
10.Hi-Pot: 1500V
AC 6S 1mA
Applications
1.Ethernet
Switches and Routers
2.Network
Interface Cards (NICs)
3.Ethernet Hubs
and Repeaters
4.IP Cameras and
Surveillance Systems
Features
-Physical Compatibility:
Compatible with standard Ethernet ports found on computers, routers, switches,
and other network devices, ensuring seamless integration into existing network
setups.
-Application
Flexibility: Used in various networking environments, including residential,
small office/home office (SOHO), educational institutions, and small business
networks, where moderate-speed Ethernet connectivity is sufficient.
-Reliability and
Performance: Provides reliable data transmission and network performance,
supporting tasks such as internet browsing, file sharing, media streaming, and
basic network communication.
-Cost-Effective
Solution: Offers a cost-effective solution for establishing Ethernet
connections, suitable for applications that do not require higher speeds
provided by Gigabit Ethernet or beyond.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
