Brand ERYCO
Product origin CHINA
Electrical
Voltage rating : 300V
Current rating : 15A
Contact Resistance: 20mΩ
Insulation Resistance: 500MΩ/DC500V
Withstanding Voltage: AC2000V/Min
Wire range: 14-22AWG 2.5mm2
Operation temperature : -40ºC to+105ºC
Product parameter:
Material:
Housing: PA66 UL94V-0
Terminal: Brass,Tin plated
Screws: M3 Steel Nickel Plated
Applications
1.Consumer Electronics
2.Test and Measurement Instruments
3.Medical Equipment
4.Automotive Electronics
Features
-Pitch Size: The 7.62mm pitch indicates the center-to-center distance between adjacent terminals, providing space for larger wire sizes compared to narrower pitches.
-Number of Poles: Specifies how many terminals or connections are available on the block, which can vary depending on the specific model and application requirements.
-Current Rating: Indicates the maximum current that the terminal block can safely handle, which is essential for ensuring reliable electrical connections without overheating.
-Voltage Rating: Specifies the maximum voltage that the terminal block is rated for, ensuring safe operation within specified electrical parameters.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
