Product parameter:
Material：
Screw: M2,
Steel,Zn plated
Shrapnel: Phosphor
bronze, Nickel plated
Pin header: Brass,
Tin plated
Housing: PA66 ,
UL94V-0
Mechanical
Temp. Range: -40 °
C ~ + 105 ° C
Soldering: 250°
C±5° C for 5S
Torque: 0.2 N.m
(1.77Lb. in)
Strip length:
4.5~5 mm
Applications
1.Renewable Energy
Systems
2.Rail and
Transportation
3.Medical Devices
4.Custom
Electronics Projects
Features
-Material:
Typically made from materials such as nylon or thermoplastic for insulation,
and conductive parts made of materials like brass or tin-plated brass. This
construction ensures durability, good electrical conductivity, and resistance
to environmental factors.
-Wire Size
Compatibility: Specifies the range of wire sizes (usually in AWG or mm²) that
can be accommodated by the terminal block. PCB terminal blocks with a 3.50mm
pitch can accommodate smaller to moderate wire gauges, allowing for flexibility
in wiring configurations.
-Mounting Style:
Designed for PCB mounting, these terminal blocks typically have through-hole
pins or surface mount (SMT) pads for soldering onto the PCB. They are designed
to withstand PCB assembly processes such as wave soldering or reflow soldering.
-Locking
Mechanism: Some terminal blocks feature locking mechanisms such as clips or
screws to secure mating connectors or wires, ensuring a reliable and stable
connection.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
