Brand ERYCO
Product origin CHINA
Rated voltage: 600V
Rated current:40A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC2000V/1Min
Product parameter:
Material
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 1.2Nm (10.6lb.in)
Strip length: 5~6mm
Applications
1.Industrial Control Panels
2.Power Supplies and Distribution
3.Building Automation
4.Consumer Electronics
Features
-Current Rating: Indicates the maximum current that the terminal block can safely handle. This rating ensures that the terminal block can manage the electrical load without overheating or causing electrical failures.
-Voltage Rating: Specifies the maximum voltage that the terminal block is rated for, ensuring safe operation within specified electrical parameters.
-Material: Terminal blocks are typically made from materials such as nylon or thermoplastic for insulation and conductive parts made of materials like brass or tin-plated brass. This construction ensures durability and good electrical conductivity.
-Wire Size Compatibility: Specifies the range of wire sizes (usually in AWG or mm²) that can be accommodated by the terminal block. This ensures compatibility with various wiring needs, allowing for flexibility in wire selection.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
