Product parameter:
Material
Screw:M2.5,
Steel,Zn plated
Shrapnel: Phosphor
bronze, Nickel plated
Pin header: Brass,
Tin plated
Housing: PA66 or
PBT, UL94V-0
Mechanical
Temp. Range: -40 °
C ~ + 105 ° C
Soldering: 250 °
C 5Sec.
Max.
Torque: 0.4 N.m
(3.5Lb. in)
Strip length:
4.5~5 mm
Applications
1.Industrial
Automation
2.Telecommunications
3.Power Supplies
and Distribution
4.LED Lighting
Systems
Features
-Voltage Rating:
Specifies the maximum voltage that the terminal block is rated for, ensuring
safe operation within specified electrical parameters.
-Material:
Typically made from materials such as nylon, thermoplastic, or ceramic for
insulation, with conductive parts made of materials like brass or tin-plated
brass. This construction ensures durability, good electrical conductivity, and
resistance to environmental factors.
-Wire Size
Compatibility: Specifies the range of wire sizes (usually in AWG or mm²) that
can be accommodated by the terminal block. PCB terminal blocks with a 5.0mm
pitch can accommodate larger wire gauges, providing flexibility in wiring
configurations for applications requiring higher current capacity.
-Mounting Style:
Designed for PCB mounting with through-hole pins or surface mount (SMT) pads,
suitable for various PCB assembly processes such as wave soldering or reflow
soldering.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
