Brand ERYCO
Product origin CHINA
Rated voltage: 300V
Rated current: 8A
Wire range: 26~14AWG 2.5mm²
Contact Resistance: 20 m Ω
Insulation resistance: 500MΩ/DC500V
Product parameter:
Material
Screw: M2.5, Steel,Zn plated
Shrapnel: Stainless steel, Nickel plated
Pin header: Brass or Steel, Tin plated
Housing: PA66 , UL94V-0
Mechanical
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
Torque: 0.4 N.m (3.54Lb. in)
Strip length: 6~7 mm
Applications
1.Automotive Electronics
2.Consumer Electronics
3.Medical Devices
4.Custom Electronics Projects
Features
-Pitch Size: The 5.0mm pitch refers to the center-to-center distance between adjacent terminals. This spacing allows for accommodating moderate wire sizes while maintaining a compact PCB layout.
-Number of Poles: Specifies the number of terminals or connections available on the block. This can vary depending on the specific model and application requirements, typically ranging from 2 poles up to multiple poles.
-Current Rating: Indicates the maximum current that the terminal block can safely handle. PCB terminal blocks with a 5.0mm pitch are designed to handle moderate to high currents suitable for various industrial and commercial applications.
-Voltage Rating: Specifies the maximum voltage that the terminal block is rated for, ensuring safe operation within specified electrical parameters.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
