Product parameter:
Material
Screw: M2.5,
Steel,Zn plated
Shrapnel:
Stainless steel, Nickel plated
Pin header: Brass
or Steel, Tin plated
Housing: PA66 ,
UL94V-0
Mechanical
Temp. Range: -40 °
C ~ + 105 ° C
Soldering: 250°
C±5° C for 5S
Torque: 0.4 N.m
(3.54Lb. in)
Strip length: 6~7
mm
Applications
1.Industrial
Automation
2.Telecommunications
3.Power Supplies
and Distribution
4.LED Lighting
Systems
Features
-Voltage Rating:
Specifies the maximum voltage that the terminal block is rated for, ensuring
safe operation within specified electrical parameters.
-Material:
Typically made from materials such as nylon, thermoplastic, or ceramic for
insulation, with conductive parts made of materials like brass or tin-plated
brass. This construction ensures durability, good electrical conductivity, and
resistance to environmental factors.
-Wire Size
Compatibility: Specifies the range of wire sizes (usually in AWG or mm²) that
can be accommodated by the terminal block. PCB terminal blocks with a 5.0mm
pitch can accommodate larger wire gauges, providing flexibility in wiring
configurations for applications requiring higher current capacity.
-Mounting Style:
Designed for PCB mounting with through-hole pins or surface mount (SMT) pads,
suitable for various PCB assembly processes such as wave soldering or reflow
soldering.
Dimensions(Please refer to the
attached 2D drawings for detailed specifications.):
