Brand ERYCO
Product origin CHINA
Electrical
Rated voltage:300V
Rated current:15A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Wire range:28-16AWG1mm²
Product parameter:
Material
Screws: M2.5steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque:0.4Nm (10.6lb.in)
Strip length:4~5mm
Applications
1.Printed Circuit Board (PCB) Assemblies
2.Industrial Control Systems
3.Telecommunications Equipment
4.Consumer Electronics
Features
-Voltage Rating: Indicates the maximum voltage (in volts) that the terminal block can withstand, ensuring safe operation within specified electrical parameters.
-Wire Size Compatibility: Supports a range of wire sizes, accommodating various conductor diameters commonly used in electronics and electrical applications.
-Termination Method: Uses a screwdriver to clamp wires into place, providing a secure and reliable connection. Some designs may feature captive screws to prevent loss during installation.
-Mounting Options: Designed for PCB (Printed Circuit Board) mounting using through-hole technology. This allows for secure attachment to the PCB, ensuring stability and reliability in various operating conditions.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
