Brand ERYCO
Product origin CHINA
Electrical :
Rated voltage:300V
Rated current:15A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Product parameter:
Material
Screws: M2.5 steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.4Nm (10.6lb.in)
Strip length: 4.5~5mm
Applications
1.Building Wiring
2.Telecommunications
3.Renewable Energy Systems
4.Prototype and Testing
Features
-Termination Type: The rising clamp mechanism allows for easy and secure wire insertion. When the screw is tightened, it clamps down on the wire, creating a secure electrical connection.
-Wire Range: Specifies the range of wire sizes that can be accommodated by the terminal block. This is usually indicated in AWG (American Wire Gauge) or mm².
-Current and Voltage Ratings: Specifies the maximum current and voltage that the terminal block can handle safely.
-Marking Options: Some terminal blocks may have options for marking labels or tags to identify connected wires.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
