Brand ERYCO
Product origin CHINA
Rated voltage: 300V
Rated current: 16A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC2000V/1Min
Wire range: 22-12AWG 2.5mm²
Product parameter:
Material
Screws: M2.5 steel Zinc plated
Contact: Brass,Ni Plated
Pin header: Brass, Tin plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.4Nm (3.54lb.in)
Strip length: 6-7mm
Applications
1.Industrial Control Panels
2.Field Wiring
3.Power Distribution
4.Automation and Instrumentation
Features
-Current and Voltage Ratings: Specifies the maximum current and voltage that the terminal block can handle safely.
-Marking Options: Some terminal blocks may have options for marking labels or tags to identify connected wires.
-Pitch Size: The pitch size refers to the distance between adjacent terminals. In this case, it's 5.00mm, which is the standard spacing for many terminal blocks.
-Number of Poles: It indicates how many individual screw terminals are present in the block. Common configurations include 2-pole, 3-pole, up to 12 or more depending on the application.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
