Brand ERYCO
Product origin CHINA
Electrical
Rated voltage:300V
Rated current:15A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Product parameter:
Material
Screws: M2.5 steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.4Nm (10.6lb.in)
Strip length: 4.5~5mm
Applications
1.PCB Mounting Applications
2.Industrial Control Systems
3.Power Distribution
4.Building Automation
Features
-Current Rating:Typically rated for 10-16A, depending on the specific model and manufacturer, indicating the maximum current the terminal block can handle safely.
-Voltage Rating:Generally rated for 300V-600V, suitable for a wide range of low to medium voltage applications.
-Insulation Resistance:High insulation resistance (typically in the megaohm range) ensures minimal leakage current and enhanced safety.
-Contact Resistance:Low contact resistance (usually in the milliohm range) ensures efficient electrical conductivity.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
