Brand ERYCO
Product origin CHINA
Electrical
Rated voltage:300V
Rated current:20A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1600V/1Min
Product parameter:
Material
Screws: M3 steel Zinc plated
Pin header: Brass, Sn plated
Housing: PA66, UL94V-0
Mechanical
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.5Nm (10.6lb.in)
Strip length: 6~7mm
Applications
1.Consumer Electronics
2.LED Lighting Systems
3.Medical Devices
4.electronics
Features
-Material: Constructed from durable materials such as brass, copper, or tin-plated copper for excellent electrical conductivity and corrosion resistance. The housing material is typically a robust thermoplastic or thermoset material that provides insulation and mechanical support.
-Current Rating: Specifies the maximum current carrying capacity (in amps) that the terminal block can safely handle, ensuring safe operation under specified electrical conditions.
-Termination Method: Features screw terminals for secure wire connection. The rising clamp mechanism allows for easy insertion and tightening of wires without the need for soldering, providing a reliable and maintenance-friendly connection.
-Mounting Options: Designed for PCB mounting using through-hole technology or other mounting methods compatible with the specific terminal block design. This ensures secure attachment to the PCB, providing stability and reliability of connections.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
