Brand ERYCO
Product origin CHINA
Housing:Hing Temperature Thermoplastic
with G.F,UL94V-0,Black
Contact:Copper Alloy,t=0.20mm.
Shell:Copper Alloy,t=0.25mm.
Product parameter:
Material:
Current Rating:1A Max.
Dielectric Withstanding Voltage:100 V AC for 1 min.
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Total Mating Force:3.57 kgf Max.
Total Unmating Force:1.0 kgf Min.
Temperature Range: -30°C Up To +80°C
Applications
1.Digital Cameras and Camcorders
2.Portable Audio Devices
3.GPS Navigation Devices
4.Embedded Systems and IoT Devices
Features
-SMD (Surface Mount Device): Designed for surface mounting directly onto a printed circuit board (PCB), offering a compact and low-profile solution.
-Design: Engineered for reliability and durability, featuring a robust housing and contacts that withstand frequent insertion and removal cycles.
-Compatibility: Compliant with Micro USB standards, ensuring compatibility with devices designed to use Micro USB connectors.
-Power and Data Transfer: Supports both power charging and data transfer functionalities, providing a versatile connection for various devices.
Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
