SMD Tactile Switch :ERYGYS1201

SMD Tactile Switch :ERYGYS1201

Brand ERYCO

Product origin CHINA

SMD Tactile Switch

ELECTRICAL

1.Rating: 50mA 12VDC

2.Contact Resistance : 50mΩ max(initial)

3.Insulation Resistance: 100MΩ(minDC 250V)

4.Dielectric Strength : AC250V(50/60Hz for 1minute)

5.Electrically Life: 100000cycles

6.Environment temperature:-20ºC~+70ºC

7.Operating Force: 180/250(±30gf)

8.Seal temperature:260ºC~ 280ºC

2D(PDF)Drawing

Product parameter:

Applications

1.Automotive Applications

2.Industrial Equipment

3.Medical Devices

4.Prototyping and DIY Projects

Features

-Low Profile: These switches are usually designed to have a low profile, making them suitable for thin and compact devices.

-No Through-Holes: Unlike through-hole components, SMD components are mounted directly onto the PCB's surface, reducing the need for holes, saving space, and improving mechanical stability.

-Contact Resistance: These switches typically feature low contact resistance, ensuring stable electrical connections during operation.

-Customizable Actuation Force: Some SMD tactile switches offer different actuation forces, allowing designers to choose the best switch based on the intended application.

Dimensions(Please refer to the attached 2D drawings for detailed specifications.):
